About This Product
PRODUCT DETAILS
Recommended Rider Height: 5' 8" - 6'
| Top Tube | 20.75" |
| Head Angle | 75.5° |
| Seat Angle | 71° |
| BB Height | 11.8" |
| Chainstay | 13.25" |
| Frame | 100% 4130 cromo tubing with removable brake mounts and guides, integrated head tube, mid bb, embossed logo top and downtube gussets |
| Fork | Cromo cnc steerer tube, integrated bearing race, tapered 1020 hi tensile steel legs with angled ends |
| Colors | Gloss Black |
| Headset | United sealed bearing, int. |
| Stem | United 52mm Reach Supreme Stem with embossed United logo on faceplate and machined recess for flush fitting topcap |
| Handlebar | 10” x 30” 100% 4130 cromo with 1° up sweep, 12° back sweep |
| Grips | United Jimmy grips & United ends |
| Seat | United Slim Tripod seat Faux quilted leather with custom sewn patch on rear |
| Seat Post | United alloy Tripod |
| Seat Post Clamp | Alloy with machined detail |
| Rims | Alloy 36h, double wall |
| Front Hub | 36h United Supreme sealed alloy, 10mm, female bolt |
| Rear Hub | 36h sealed LHD United Supreme freecoaster hub 14mm axle, 9t driver |
| Spokes |
|
| Tires | United Direct 20 x 2.4” |
| Crankset | 3pc LHD 175mm, heat treated cromo, 8 spline, stamped United logo |
| Bottom Bracket | United sealed bearing mid |
| Pedals | United x Marie Jade Valentino PC pedals |
| Brake | Tektro 990 |
| Brake Lever | Alloy |
| Chain | United Supreme X410 |
| Gearing | United 25t, steel |
| Extras | 4 x steel 100mm |
Weight: 26lbs / 11.8KG
Additional Information
| Barcode | 139360 |
|---|---|
| Special Shipping Group | No |
NOTE: Complete Bike specifications and components may differ from photos and description. Manufacturers reserve the right to make changes and/or substitutions due to parts availability, production requirements and ongoing development decisions.
