About This Product
PRODUCT DETAILS
Recommended Rider Height: 5' - 5' 8"
| Top Tube | 20" |
| Head Angle | 75° |
| Seat Angle | 71° |
| BB Height | 11.8" |
| Chainstay | 13.25" |
| Frame | 1020 hi ten, welded brake mounts, 1 1/8" head tube, mid bb, embossed logo top tube gusset |
| Fork | Cnc steerer tube, 1020 tapered hi tensile steel legs |
| Colors | Gloss Gray |
| Headset | 1 1/8" A Headset painted to match bike frame colour |
| Stem | United 50mm reach top load stem with embossed United logo on faceplate and forged detailing on sides |
| Handlebar | 8.25” x 27” 1020 hi tensile steel with 1.5° up sweep, 11° back sweep |
| Grips | United & United ends |
| Seat | United Padded Seat/Post Combo with custom sewn patch on rear |
| Seat Post | Integrated with seat |
| Seat Post Clamp | Alloy |
| Rims | Alloy 36h, single wall |
| Front Hub | 36h, 10mm axle |
| Rear Hub | 36h sealed alloy cassette hub with 14mm axle, sealed bearing 9t driver, 4 pawl, ultra loud mechanism |
| Spokes |
|
| Tires | United Direct 20 x 2.3”(F), United Direct 20 x 2.1”(R) |
| Crankset | 3pc 165mm, Tubular, 8 spline, printed United logo |
| Bottom Bracket | United sealed bearing mid |
| Pedals | Ultra Slim Nylon plastic |
| Brake | 990 |
| Brake Lever | Alloy |
| Chain | United Supreme X410 |
| Gearing | United 25t, steel |
| Extras |
|
Weight: 24.9 lbs / 11.29 kg
Additional Information
| Barcode | 139356 |
|---|---|
| Special Shipping Group | No |
NOTE: Complete Bike specifications and components may differ from photos and description. Manufacturers reserve the right to make changes and/or substitutions due to parts availability, production requirements and ongoing development decisions.
