About This Product
PRODUCT DETAILS
Recommended Rider Height: 4' 4" - 4' 9"
| Top Tube | 18″ |
| Head Angle | 73.5° |
| Seat Angle | 70° |
| BB Height | 10.5″ |
| Chainstay | 12.5″ |
| Frame | 18" Top tube Integrated headtube |
| Fork | CrMo Straight 3/8″ |
| Colors | Trans Oxblood |
| Headset | Integrated 45°/45° Sealed 41.8MM |
| Stem | Top Load |
| Handlebar | 2 Piece 8” X 28” |
| Grips | OG |
| Seat | Text. Nylon & Syn. Leather |
| Seat Post | Integrated Alloy |
| Seat Post Clamp | Single 5mm Bolt |
| Rims | Revenge SW1 36H |
| Front Hub | Alloy 3/8″ Axle |
| Rear Hub | Sealed Cassette 14MM/1pc Driver |
| Spokes | 14G Brass Nipples |
| Tires | 2.25 T/A 65 PSI |
| Crankset | CrMo 150mm 8 Spline |
| Bottom Bracket | Sealed Bearing MID |
| Pedals | Nylon Loose Ball |
| Brake | Alloy 990 U-Brake, Soft Compound Pads |
| Brake Lever | Alloy Short Reach |
| Chain | KMC Z410H |
| Gearing | 25/9 CrMo KEY 25T |
| Extras |
|
Weight: 22.55 LBS / 10.22 KG
Additional Information
| Barcode | 133736 |
|---|---|
| Special Shipping Group | No |
NOTE: Complete Bike specifications and components may differ from photos and description. Manufacturers reserve the right to make changes and/or substitutions due to parts availability, production requirements and ongoing development decisions.
